LQ-BTB-300A/LQ-BTB-350 Overwrapping Machine For Box

Short Description:

This machine is widely applicable to the automatic film packaging (with gold tear tape) of various single boxed articles. With new-type of double safeguard, no need to stop the machine, other spare parts will not be damaged when the machine runs out of step. Original unilateral hand swing device to prevent adverse shaking of the machine,And the non-rotation of the hand wheel when the machine keeps running to secure the security of the operator. No need to adjust the height of worktops on both sides of the machine when you need to replace moulds, no need to assemble or dismantle the material discharge chains and discharge hopper.


Product Detail

video1

video2

Product Tags

APPLY PHOTOS

Machine For Box  (3)
Machine For Box  (2)

INTRODUCTION

This machine is widely applicable to the automatic film packaging (with gold tear tape) of various single boxed articles. With new-type of double safeguard, no need to stop the machine, other spare parts will not be damaged when the machine runs out of step. Original unilateral hand swing device to prevent adverse shaking of the machine,And the non-rotation of the hand wheel when the machine keeps running to secure the security of the operator. No need to adjust the height of worktops on both sides of the machine when you need to replace moulds, no need to assemble or dismantle the material discharge chains and discharge hopper.

Machine For Box  (5)
Machine For Box  (6)
Machine For Box  (4)
Machine For Box  (1)

TECHNICAL PARAMETER

Model LQ-BTB-300A LQ-BTB-350
Packing Material BOPP film and gold tear tape BOPP film and gold tear tape
Packing Speed 40-70 packs/Min 30~60 packs/min
Max Packing Size (L)240×(W)120×(H)60mm (L)300×(W)120×(H)60mm
Electric Supply & Power 220V 50Hz  5kw 220V 50Hz  5kw
Weight 500kg 600kg
Overall Dimensions 2000×700×1400mm(L*W*H) (L)2000×(W)800×(H)1400mm

FEATURE

1. No need to regulate the height of two work tops of the machine when the mould need to be replaced, no need to assemble or dismantle the material discharge chains and discharge hopper. Reduce the replacement time of the mould four hours to the present 30 minutes.

2. New-type double safeguard mechanisms are used, hence other spare parts will not be damaged when the machine runs out of step without stop of the machine.

3.Original unilateral hand swing device to prevent the machine shaking adversely, and the non-rotation of the hand wheel during the running of the machine can secure the security of the operator.

4. New-type double-rotary film cutter can ensure no need to mill the blade during many-year use of the machine, which overcomes the defect that the traditional stationary single-rotary film cutting cutter was easily worn.

TERMS OF PAYMENT AND WARRANTY

Terms of Payment:

30% deposit by T/T when confirming the order,70% balance by T/T before shipping.Or irrevocable L/C at sight.

Warranty:

12 months after B/L date
