LQ-NJP Automatic Hard Capsule Filling Machine

Short Description:

LQ-NJP series fully automatic capsule filling machine is designed and further improved on the base of original full automatic capsule filling machined,with high technology and exclusive performance. Its function can reach leading level in China. It is an ideal equipment for capsule and medicine in pharmaceutical industry.


Product Detail

Video

Product Tags

APPLY PHOTOS

LQ-NJP (2)

INTRODUCTION

LQ-NJP series fully automatic capsule filling machine is designed and further improved on the base of original full automatic capsule filling machined,with high technology and exclusive performance. Its function can reach leading level in China. It is an ideal equipment for capsule and medicine in pharmaceutical industry.

LQ-NJP (6)
LQ-NJP (1)
LQ-NJP (5)
LQ-NJP (4)

TECHNICAL PARAMETER

Model

LQ-NJP-400

LQ-NJP-800

LQ-NJP-1200

LQ-NJP-2300

Capacity

400pcs/min

800pcs/min

1200pcs/min

2300pcs/min

Quantity Of Die Holes

3

6

9

18

Capsule Size

NO.00-5

Fining Precision

>99%

Voltage

380V/50Hz/3Ph

Power

3.5kw

5kw

5.5kw

8kw

Noise

<80dBA

Vacuum Degree

0.02-0.06Mpa

Overall Dimension(L*W*H)

700*800*

1700mm

860*960*1800mm

960*1000*1900mm

1180*1300*

1900mm

Weight

700kg

900kg

1100kg

1500kg

TECHNICAL PARAMETER

1. Good-looking appearance, exquisite workmanship, ease of operation, simplicity of use.

2. Stowage seat and measuring plate is designed as one unit to make measuring plate and stowage rod without deviation phenomenon, avoid friction phenomenon between stowage rod and measuring plate, improve its precision highly, furthermore, it prolongs the machine's life greatly.

3. Ineligible capsule can be eliminated automatically. The medicine in the capsule can be recycled and be reused, thus it can increase greatly economic efficiency.

4. Simplicity and convenience of dismantling, installation and clean, various models of mould can be replaced each other, the mould of 800 model and 1000 model as well as 1200 model can be replaced mutually on the same machine to meet different requirement of capacity.

5. Dust collector and vacuum pipe as well as waste air pipe are installed in the inner of the machine to avoid the air pipe becoming hard, broken and leakage etc phenomenon, it is more convenient to clean the platform. Furthermore, it accords with the requirement of GMP that medicine can not contact with organic material.

6. The cap of stowage rod is made of stainless steel which replaces original plastic cap to void breaking phenomenon; the screws and caps on the platform is less than before.

TERMS OF PAYMENT AND WARRANTY

Terms of Payment:

30% deposit by T/T when confirming the order,70% balance by T/T before shipping. Or irrevocable L/C at sight.

Warranty:

12 months after B/L date.
