LQ-TDP Single Tablet Press Machine

Short Description:

This machine is used for molding different kinds of granular raw materials into round tablets. It is applicable to trial manufacturing in Lab or batch produce in small amount different kinds of tablet, sugar piece, calcium tablet and tablet of abnormal shape. It features a small desktop type press for motive and continual sheeting. Only one pair of punching die can be erected on this press. Both filling depth of material and thickness of tablet are adjustable.


Product Detail

Video

Product Tags

APPLY PHOTOS

LQ-TDP Single Tablet Press Machine

INTRODUCTION

This machine is used for molding different kinds of granular raw materials into round tablets. It is applicable to trial manufacturing in Lab or batch produce in small amount different kinds of tablet, sugar piece, calcium tablet and tablet of abnormal shape. It features a small desktop type press for motive and continual sheeting. Only one pair of punching die can be erected on this press. Both filling depth of material and thickness of tablet are adjustable.

FEATURE

1. Design of GMP.

2. High quality with low price.

3. Easily remove parts for quick machine`s maintenance.

TECHNICAL PARAMETER

Model

LQ-TDP-0

LQ-TDP-1

LQ-TDP-2

LQ-TDP-3

LQ-TDP-4

LQ-TDP-5

LQ-TDP-6

Max.Pressure

10 KN

15 KN

20 KN

30 KN

40 KN

50 KN

60 KN

Max. Dia of Tablet

10 mm

12 mm

13 mm

14 mm

15 mm

22 mm

25 mm

Max. Thickness of Tablet

6 mm

6 mm

6 mm

6 mm

6 mm

7 mm

7.5 mm

Max. Depth of Filling

12 mm

12 mm

12 mm

12 mm

12 mm

15 mm

15 mm

Capacity

6000 pcs/h

6000 pcs/h

6000 pcs/h

6000 pcs/h

6000 pcs/h

3600 pcs/h

3600 pcs/h

Voltage

220V / 50Hz / 1Ph

220V / 50Hz / 1Ph

220V / 50Hz / 1Ph

220V / 50Hz / 1Ph

220V / 50Hz / 1Ph

220V / 50Hz / 1Ph

220V / 50Hz / 1Ph

Power

0.37w

0.37w

0.37w

0.55w

0.55w

0.75w

1.1w

Overall Dimension(L*W*H)

530*340*

570 mm

530*340*

570 mm

530*360*

570 mm

680*440*

740 mm

680*450*

740 mm

600*500*

700 mm

650*500*

700 mm

Weight

35 kg

60 kg

75 kg

80 kg

95 kg

150 kg

165 kg

TERMS OF PAYMENT AND WARRANTY

Terms of Payment:

30% deposit by T/T when confirming the order, 70% balance by T/T before shipping. Or irrevocable L/C at sight.

Warranty:

12 months after B/L date.
