LQ-ZP Automatic Rotary Tablet Pressing Machine

Short Description:

This machine is a continuous automatic tablet press for pressing granular raw materials into tablets. Rotary tablet pressing machine is mainly used in pharmaceutical industry and also in the chemical, food, electronic, plastic and metallurgical industries.

All the controller and devices are located in one side of the machine, so that it can be easier to operate. An overload protection unit is included in the system to avoid the damage of the punches and apparatus, when overload occurs.

The machine’s worm gear drive adopts fully-enclosed oil-immersed lubrication with long service-life, prevent cross pollution.


Product Detail

Video

Product Tags

APPLY PHOTOS

LQ-ZP (1)

INTRODUCTION

This machine is a continuous automatic tablet press for pressing granular raw materials into tablets. Rotary tablet pressing machine is mainly used in pharmaceutical industry and also in the chemical, food, electronic, plastic and metallurgical industries.

TECHNICAL PARAMETER

Model

LQ-ZP11D

LQ-ZP15D

LQ-ZP17D

LQ-ZP19D

LQ-ZP21D

Quantity of Die

11

15

17

19

21

Max. Pressure

100 KN

80 KN

60 KN

60 KN

60 KN

Max. Dia. of Tablet

40 mm

25 mm

20 mm

15 mm

12 mm

Max. Thickness of Tablet

28 mm

15 mm

15 mm

15 mm

15 mm

Max. Depth of Filling

10 mm

6 mm

6 mm

6 mm

6 mm

Rotate Speed

20 rpm

30 rpm

30 rpm

30 rpm

30 rpm

Max. Capacity

13200 pcs/h

27000 pcs/h

30600 pcs/h

34200 pcs/h

37800 pcs/h

Power

3 kw

3 kw

3 kw

3 kw

3 kw

Voltage

380V, 50Hz, 3Ph

380V, 50Hz, 3Ph

380V, 50Hz, 3Ph

380V, 50Hz, 3Ph

380V, 50Hz, 3Ph

Overall Dimension
(L*W*H)

890*620*1500 mm

890*620*1500 mm

890*620*1500 mm

890*620*1500 mm

890*620*1500 mm

Weight

1000 kg

1000 kg

1000 kg

1000 kg

1000 kg

FEATURE

1. The outside part of the machine is fully-enclosed and it is made of stainless steel to meet the GMP requirement.

2. It has transparent windows so that pressing condition can be observed clearly and the windows can be opened. Cleaning and maintenance are easier.

3. This machine has features of high pressure and large size of tablet. This machine are suitable for small amount production and various kinds of tablets, such as round, irregular and annular tablets.

4. All the controller and devices are located in one side of the machine, so that it can be easier to operate. An overload protection unit is included in the system to avoid the damage of the punches and apparatus, when overload occurs.

5. The machine's worm gear drive adopts fully-enclosed oil-immersed lubrication with long service-life, prevent cross pollution.

TERMS OF PAYMENT AND WARRANTY

Terms of Payment: 30% deposit by T/T when confirming the order,70% balance by T/T before shipping. Or irrevocable L/C at sight.

Delivery Time: 30 days after receiving deposit.

Warranty: 12 months after B/L date.
